DC/DCコンバータ
《対象製品：109件》 | 写真 | 用途 | シリーズ名 (モデル数) |
パッケージ | 出力電力 | 入力電圧 （VDC） |
出力電圧 （VDC） |
絶縁耐圧 |
取得安全規格最新情報は、必ずお問合わせ下さい。 | 備考 | |
|---|---|---|---|---|---|---|---|---|---|---|
|
産業用
|
CRS-240
(24) |
Eurocard 3U standard | 180-280W | 9-15, 18-30, 36-72, 50.4-90, 77-144, 165-275 | 5,12,24,48 | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 | |||
|
産業用
|
CRS-120
(24) |
Eurocard 3U standard | 100-140W | 9-15, 18-30, 36-72, 50.4-90, 77-144, 156-275 | 5,12,24,48 | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 | |||
|
産業用
|
CRS-60
(20) |
127x84.5x40mm | 50-60W | 9-15, 18-30, 36-60, 50.4-90, 77-144 | 12,24,48,72,110 | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 | |||
|
産業用
鉄道用
|
CVS-280
(4) |
65x162x230mm | 280W | 600/750 | 24,48,72,110 | EN50155 EN45545-2 EN 50121-3-2 UL/cUL/IEC/EN62368-1 | |||
|
産業用
鉄道用
|
CLS-120
(3) |
Eurocard 3U standard | 120W | 14.4-154 | 12, 24, 48 | EN50155 EN45545-2 EN 50121-3-2 UL/cUL/IEC/EN62368-1 | |||
|
産業用
鉄道用
|
CRS-2000
(14) |
Eurocard 3U standard | 2000W | 14.4-33.6, 21.6-50.4, 28.8-67.2, 43.2-100.8, 66-154 | 24,48,72,110 | EN50155 EN45545-2 EN 50121-3-2 UL/cUL/IEC/EN62368-1 | |||
|
産業用
鉄道用
|
CBS-10K
(4) |
455.4 x 217.4 x 84.8mm | 3500-6000W(ピーク10kW) | 16.8-30,33.6-60,50.4-90,77-138 | 500 | UL/cUL/IEC/EN 62368-1 EN50155 EN45545-2 CE-Marking | |||
|
産業用
|
MDWI15
(12) |
DIP | 15W | 9-36,18-75 | 5.1,12,15,24,±12,±15 | 1500VDC | UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MDW15
(18) |
DIP | 15W | 9-18,18-36,36-75 | 5.1,12,15,24,±12,±15 | 1500VDC | UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
鉄道用
|
MRZI150
(5) |
クォーターブリック | 150W | 36-160 | 5,12,15,24,54 | 2000VAC | UL/cUL/IEC/EN 62368-1 EN50155 EN45545-2 | ||
|
産業用
鉄道用
|
MRZI100
(5) |
クォーターブリック | 100W | 36-160 | 5,12,15,24,54 | 2000VAC | UL/cUL/IEC/EN 62368-1 EN50155 EN45545-2 | ||
|
産業用
鉄道用
|
MKZI40
(7) |
2"×1" | 40W | 36-160 | 5,12,15,24,±12,±15 | 3000VAC | UL/cUL/IEC/EN 62368-1 EN50155 EN45545-2 | ||
|
産業用
超高絶縁
|
MIE10-HI
(24) |
DIP | 10W | 9-18, 18-36, 36-75 | 3.3, 5, 5.1, 12, 15, 24, ±12, ±15 | 9000VDC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
超高絶縁
|
MAEU01-HI
(9) |
SIP | 1W | 4.5- 5.5, 10.8-13.2, 21.6-26.4 | 5,12,15 | 8000VDC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
超高絶縁
|
MSCEU01-HI
(15) |
SMD | 1W | 4.5- 5.5, 10.8-13.2, 21.6-26.4 | 5,12,15,24,±12,±15 | 8000VDC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
|
MFSU01
(9) |
DIP | 1W | 4.5- 5.5, 10.8-13.2, 21.6-26.4 | 5,12,15 | 1500VDC | |||
|
産業用
|
MCWI04
(12) |
SIP | 4W | 9-36, 18-75 | 5,12,15,24,±12,±15 | 1600VDC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
|
MCW04
(18) |
SIP | 4W | 9-18, 18-36, 36-75 | 5,12,15,24,±12,±15 | 1600VDC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
|
MBSU03
(9) |
SIP | 3W | 4.5- 5.5, 10.8-13.2, 21.6-26.4 | 5,12,15 | 1500VDC | |||
|
産業用
超高絶縁
|
MQA40C
(9) |
シャーシ, DINレール | 40W | 80-160 | 5, 5.1, 12, 15, 24, 48, ±12, ±15, ±24 | 3000VAC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
超高絶縁
|
MOA20C
(9) |
シャーシ, DINレール | 20W | 80-160 | 5, 5.1, 12, 15, 24, 48, ±12, ±15, ±24 | 3000VAC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
超高絶縁
|
MKA10C
(9) |
シャーシ, DINレール | 10W | 80-160 | 5, 5.1, 12, 15, 24, 48, ±12, ±15, ±24 | 3000VAC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
超高絶縁
|
MJA06C
(9) |
シャーシ, DINレール | 6W | 80-160 | 5, 5.1, 12, 15, 24, 48, ±12, ±15, ±24 | 3000VAC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
|
MKWI10C
(18) |
シャーシ, DINレール | 10W | 9-36, 18-75 | 5, 5.1, 12, 15, 24, 48, ±12, ±15, ±24 | 3000VDC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
|
MJWI06C
(18) |
シャーシ, DINレール | 6W | 9-36, 18-75 | 5, 5.1, 12, 15, 24, 48, ±12, ±15, ±24 | 3000VDC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
|
MJWI30
(14) |
1"×1" | 30W | 9-36, 18-75 | 3.3, 5, 12, 15, 24, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
|
MDW12
(21) |
DIP | 12W | 9-18, 18-36, 36-75 | 5, 5.1, 12, 15, 24, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
|
MDW10
(24) |
DIP | 10W | 9-18, 18-36, 36-75 | 3.3, 5, 5.1, 12, 15, 24, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
超高絶縁
|
MRA60C
(9) |
シャーシ, DINレール | 60W | 80-160 | 5, 5.1, 12, 15, 24, 48, ±12, ±15, ±24 | 3000VAC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
|
MDWI12
(14) |
DIP | 12W | 9-36, 18-75 | 5, 5.1, 12, 15, 24, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
医療用
|
MIW10M
(24) |
DIP | 10W | 9-18, 18-36, 36-75 | 3.3, 5, 5.1, 12, 15, 24, ±12, ±15 | 5000VAC | IEC/EN 60601-1 ANSI/AAMI ES60601-1 CE-Marking EN 50121-4 | ||
|
産業用
鉄道用
|
CKR-2000
(15) |
Sub-rack 19'' 3U | 240-2240W | 48, 110 | 12,24,48 | UL/cUL/IEC/EN 60950-1 EN50155 CE-Marking EN 50121-3-2 EN 50121-4 | |||
|
鉄道用
|
CRS-1000
(20) |
24,36,48,72,110 | 24,48,72,110 | UL/cUL/IEC/EN 60950-1 EN50155 EN 50121-3-2 EN 50121-4 | 詳細はデータシートをご確認お願いします。 | ||||
|
鉄道用
|
CRS-500
(15) |
24,36,48,72,110 | 24,48,110 | UL/cUL/IEC/EN 60950-1 EN50155 EN 50121-3-2 EN 50121-4 | 詳細はデータシートをご確認お願いします。 | ||||
|
鉄道用
|
CTS-240
(24) |
24,36,48,72,110,220 | 5,12,24,48 | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 EN50155 EN 50121-3-2 EN 50121-4 | 詳細はデータシートをご確認お願いします。 | ||||
|
鉄道用
|
CTS-120
(20) |
24,36,48,72,110 | 5,12,24,48 | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 EN50155 EN 50121-3-2 EN 50121-4 | 詳細はデータシートをご確認お願いします。 | ||||
|
鉄道用
|
CTS-60
(25) |
24,36,48,72,110 | 5,12,16,24,48 | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 EN50155 EN 50121-3-2 EN 50121-4 | 詳細はデータシートをご確認お願いします。 | ||||
|
産業用
|
M78AR-0.5
(9) |
SIP | 0.5A | 4.75-32, 6.5-32, 8-32, 11-32, 15-32, 18-32 | 1.5, 1.8, 2.5, 3.3, 5, 6.5, 9, 12, 15 | 非絶縁 | |||
|
産業用
|
M78SAR-0.5
(9) |
SMD | 0.5A | 4.75-32, 6.5-32, 8-32, 11-32, 15-32, 18-32 | 1.5, 1.8, 2.5, 3.3, 5, 6.5, 9 | 非絶縁 | |||
|
産業用
|
M78AR-1
(3) |
SIP | 1A | 6.5-32, 15-32 | 3.3, 5, 12 | 非絶縁 | |||
|
産業用
|
MFPU01H
(21) |
DIP | 1W | 2.97-3.63, 4.5-5.5, 10.8-13.2, | 3.3, 5, 12, 15, ±5, ±12, ±15 | 3000VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
|
MBU100
(15) |
SIP | 1W | 2.97-3.63, 4.5-5.5, 10.8-13.2, 21.6-26.4 | 3.3, 5, 9, 12, 15 | 1000VDC | |||
|
産業用
|
MAW01
(24) |
SIP | 1W | 4.5-9, 9-18, 18-36, 36-75 | 5, 12, 15, 24, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 | ||
|
産業用
超高絶縁
|
MA01-HI
(40) |
SIP | 1W | 4.5-5.5, 10.8-13.2, 13.5-16.5, 21.6-26.4 | 3.3, 5, 9, 12, 15, ±5, ±9, ±12, ±15, +15/-9 | 5200VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report | ||
|
産業用
|
MAU100
(33) |
SIP | 1W | 4.5-5.5, 10.8-13.2, 13.5-16.5, 21.6-26.4 | 3.3, 5, 9, 12, 15, ±5, ±9, ±12, ±15 | 1000VDC | UL/cUL/IEC/EN 60950-1 CB-Report | ||
|
産業用
|
MAU200
(27) |
SIP | 1W | 4.5-5.5, 10.8-13.2, 21.6-26.4 | 3.3, 5, 9, 12, 15, ±5, ±9, ±12, ±15 | 3000VDC | UL/cUL/IEC/EN 60950-1 CB-Report | ||
|
産業用
|
MAPU01H
(32) |
SIP | 1W | 2.97-3.63, 4.5-5.5, 10.8-13.2, 21.6-26.4 | 3.3, 5, 9, 12, 15, ±5, ±12, ±15 | 3000VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
医療用
産業用
|
MAU400
(12) |
SIP | 1W | 4.5-5.5, 10.8-13.2 | 5, 12, 15, ±5, ±12, ±15 | 3000VAC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 IEC/EN 60601-1 ANSI/AAMI ES60601-1 CB-Report CE-Marking | ||
|
医療用
|
MAU01M
(9) |
SIP | 1W | 4.5-5.5, 10.8-13.2, 21.6-26.4 | 5, 12, 15 | 4000VAC | IEC/EN 60601-1 ANSI/AAMI ES60601-1 CB-Report CE-Marking | ||
|
産業用
|
MSLU100
(24) |
SMD | 1W | 4.5-5.5, 10.8-13.2, 13.5-16.5, 21.6-26.4 | 3.3, 5, 9, 12, 15, ±5, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report | ||
|
産業用
|
MSLU300
(21) |
SMD | 1W | 4.5-5.5, 10.8-13.2, 21.6-26.4 | 3.3, 5, 12, 15, ±5, ±12, ±15 | 3000VDC | |||
|
産業用
|
MSPU01H
(21) |
SMD | 1W | 2.97-3.63, 4.5-5.5, 10.8-13.2 | 3.3, 5, 12, 15, ±5, ±12, ±15 | 3000VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MSCW01
(20) |
SMD | 1W | 4.5-9, 9-18, 18-36, 36-75 | 5, 12, 15, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report | ||
|
医療用
|
MSCU01M
(15) |
SMD | 1W | 4.5-5.5, 10.8-13.2, 21.6-26.4 | 5, 12, 15, ±12, ±15 | 4000VAC | IEC/EN 60601-1 ANSI/AAMI ES60601-1 CB-Report CE-Marking | ||
|
産業用
超高絶縁
|
MDEU02-HI
(15) |
DIP | 2W | 4.5-5.5, 10.8-13.2, 21.6-26.4 | 5, 12, 15, ±12, ±15 | 8000VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MFW02
(28) |
DIP | 2W | 4.5-10, 9-18, 18-36, 36-75 | 3.3, 5, 12, 15, ±5, ±12, ±15 | 1500VDC) | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
超高絶縁
|
MAEU02-HI
(40) |
SIP | 2W | 4.5-5.5, 10.8-13.2, 13.5-16.5, 21.6-26.4 | 3.3, 5, 9, 12, 15, ±5, ±9, ±12, ±15, +15/-9 | 5700VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report | ||
|
医療用
産業用
|
MDHU100
(15) |
DIP | 2W | 4.5-5.5, 10.8-13.2, 21.6-26.4 | 5, 12, 15, ±12, ±15 | 4000VAC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 ANSI/AAMI ES60601-1 CB-Report CE-Marking IEC/EN6060101 | ||
|
産業用
|
MCW1000
(12) |
SIP | 2W | 4.5-9, 9-18, 18-36, 36-75 | 3.3, 5, 12 | 1000VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report | ||
|
産業用
|
MCWI02
(21) |
SIP | 2W | 4.5-18, 9-36, 18-75 | 3.3-15 | 3.3, 5, 12, 15, ±5, ±12, ±15 | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report | ||
|
産業用
|
MSLU400
(16) |
SMD | 2W | 4.5-5.5, 10.8-13.2, 21.6-26.4 | 3.3, 5, 12, ±5, ±12, ±15 | 1500VDC | |||
|
産業用
|
MSDW1000
(28) |
SMD | 2W | 4.5-9, 9-18, 18-36, 36-75 | 3.3-15 | 3.3, 5, 12, 15, ±5, ±12, ±15 | UL/cUL/IEC/EN 60950-1 CB-Report | ||
|
産業用
|
MSCWI02
(18) |
SMD | 2W | 4.5-12, 9-36, 18-75 | 5, 12, 15, 24, ±12,±15 | 1500VDC | UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
医療用
産業用
|
MSHU100
(15) |
SMD | 2W | 4.5-5.5, 10.8-13.2, 21.6-26.4 | 5, 12, 15, ±12, ±15 | 4000VAC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 IEC/EN 60601-1 ANSI/AAMI ES60601-1 CB-Report CE-Marking | ||
|
産業用
|
MIWI03
(16) |
DIP | 3W | 9-36, 18-75 | 3.3, 5, 12, 15, 24, ±5, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MDWI03
(16) |
DIP | 3W | 9-36, 18-75 | 3.3, 5, 12, 15, 24, ±5, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 62368-1 CB-Report | ||
|
産業用
鉄道用
|
MIZI03
(15) |
DIP | 3W | 9-36, 18-75, 40-160 | 5, 12, 15, ±12, ±15 | 3000VAC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 EN50155 CB-Report CE-Marking | ||
|
産業用
|
MIW03
(32) |
DIP | 3W | 4.5-9, 9-18, 18-36, 36-75 | 3.3, 5, 12, 15, 24, ±5, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
医療用
産業用
|
MIHW2000
(12) |
DIP | 3W | 9-40, 18-80, 36-160 | 5, 12, ±12, ±15 | 4000VAC | UL/cUL/IEC/EN 60950-1 IEC/EN 60601-1 ANSI/AAMI ES60601-1 CB-Report CE-Marking | ||
|
産業用
|
MFW03
(28) |
DIP | 3W | 4.5-10, 9-18, 18-36, 36-75 | 3.3, 5, 12, 15, ±5, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MCW03
(28) |
SIP | 3W | 4.5-9, 9-18, 18-36, 36-75 | 3.3, 5, 12, 15, ±5, ±12, ±15 | 1600VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report | ||
|
産業用
|
MCWI03
(21) |
SIP | 3W | 4.5-18, 9-36, 18-75 | 3.3, 5, 12, 15, ±5, ±12, ±15 | 1600VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report | ||
|
産業用
|
MSCWI03
(18) |
SMD | 3W | 4.5-12, 9-36, 18-75 | 5, 12, 15, 24, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CE-Marking | ||
|
産業用
超高絶縁
|
MIE03-HI
(21) |
DIP | 3.5W | 4.5-9, 9-18, 18-36, 36-75 | 5, 5.8, 12, 15, 24, ±12, ±15 | 9000VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
医療用
|
MIW03M
(21) |
DIP | 3.5W | 4.5-9, 9-18, 18-36, 36-75 | 5, 5.8, 12, 15, ±12, ±15 | 5000VAC | IEC/EN 60601-1 ANSI/AAMI ES60601-1 CB-Report CE-Marking | ||
|
産業用
|
MCWI05
(21) |
SIP | 5W | 4.5-18, 9-36, 18-75 | 3.3, 5, 12, 15, 24, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report | ||
|
産業用
|
MDWI06
(14) |
DIP | 6W | 9-36, 18-75 | 3.3, 5, 12, 15, 24, ±12, ±15 | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | |||
|
産業用
超高絶縁
|
MIE06-HI
(18) |
DIP | 6W | 9-18, 18-36, 36-75 | 5, 12, 15, 24, ±12, ±15 | 9000VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MIW06
(24) |
DIP | 6W | 9-18, 18-36, 36-75 | 3.3, 5, 12, 15, 24, ±5, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report | ||
|
産業用
|
MIWI06
(16) |
DIP | 6W | 9-36, 18-75 | 3.3, 5, 12, 15, 24, ±5, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report | ||
|
医療用
|
MIW06M
(15) |
DIP | 6W | 9-18, 18-36, 36-75 | 5, 12, 15, ±12, ±15 | 5000VAC | IEC/EN 60601-1 ANSI/AAMI ES60601-1 CB-Report CE-Marking | ||
|
産業用
|
MSGWI06
(16) |
SMD | 6W | 9-36, 18-75 | 3.3, 5, 12, 15, 24, ±5, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report | ||
|
産業用
|
MDW08
(21) |
DIP | 8W | 9-18, 18-36, 36-75 | 3.3, 5, 12, 15, 24, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MDWI08
(14) |
DIP | 8W | 9-36, 18-75 | 3.3, 5, 12, 15, 24, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MJW10
(24) |
1"×1" | 10W | 9-18, 18-36, 36-75 | 3.3, 5, 5.1, 12, 15, ±5, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MJWI10
(18) |
1"×1" | 10W | 9-36, 18-75 | 3.3, 5, 5.1, 12, 15, 24, ±5, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
鉄道用
|
MKZI10
(18) |
2"×1" | 10W | 9-36, 18-75, 40-160 | 5, 12, 15, 24, ±12, ±15 | 3000VAC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 EN50155 EN45545-2 CB-Report CE-Marking | ||
|
産業用
|
MDWI10
(16) |
DIP | 10W | 9-36, 18-75 | 3.3, 5, 5.1, 12, 15, 24, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MIW10
(21) |
DIP | 10W | 9-18, 18-36, 36-75 | 3.3, 5, 5.1, 12, 15, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report | ||
|
産業用
|
MIWI10
(16) |
DIP | 10W | 9-36, 18-75 | 3.3, 5, 5.1, 12, 15, 24, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report | ||
|
産業用
|
MJW15
(21) |
1" x 1" | 15W | 9-18, 18-36, 36-75 | 3.3, 5, 12, 15, 24, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MJWI15
(14) |
1" X 1" | 15W | 9-36, 18-75 | 3.3, 5, 12, 15, 24, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
超高絶縁
|
MKE15-HI
(21) |
2"x1" | 15W | 9-18, 18-36, 36-75 | 5, 5.1, 12, 15, 24 ±12, ±15 | 8000VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
医療用
|
MKW15M
(21) |
2" X 1" | 15W | 9-18, 18-36, 36-75 | 5, 5.1, 12, 15, 24, ±12, ±15 | 4200VAC | IEC/EN 60601-1 ANSI/AAMI ES60601-1 CB-Report CE-Marking | ||
|
産業用
|
MJWI20
(14) |
1" X 1" | 20W | 9-36, 18-75 | 3.3, 5, 12, 15, 24, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
鉄道用
|
MKZI20
(18) |
2"x1" | 20W | 9-36, 18-75, 40-160 | 5, 12, 15, 24, ±12, ±15 | 3000VAC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 EN50155 EN45545-2 CB-Report CE-Marking | ||
|
産業用
超高絶縁
|
MKE20-HI
(21) |
2"x1" | 20W | 9-18, 18-36, 36-75 | 5, 5.1, 12, 15, 24 ±12, ±15 | 8000VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
医療用
|
MKW20M
(21) |
2" X 1" | 20W | 9-18, 18-36, 36-75 | 5, 5.1, 12, 15, 24, ±12, ±15 | 4200VAC | IEC/EN 60601-1 ANSI/AAMI ES60601-1 CB-Report CE-Marking | ||
|
産業用
|
MOWI20C
(8) |
シャーシ, DINレール | 20W | 9-36, 18-75 | 5.1, 12, 24, 48 | 2500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MJW25
(18) |
1" X 1" | 25W | 9-18, 18-36, 36-75 | 3.3, 5, 12, 15, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MJWI25
(12) |
1" X 1" | 25W | 9-36, 18-75 | 3.3, 5, 12, 15, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MKW40
(21) |
2" X 1" | 40W | 9-18, 18-36, 36-75 | 3.3, 5, 12, 15, 24, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report | ||
|
産業用
|
MKWI40
(14) |
2" X 1" | 40W | 9-36, 18-75 | 3.3, 5, 12, 15, 24, ±12, ±15 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MQWI40C
(8) |
シャーシ, DINレール | 40W | 9-36, 18-75 | 5.1, 12, 24, 48 | 2500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MKW50
(15) |
2" X 1" | 50W | 9-18, 18-36, 36-75 | 3.3, 5, 12, 15, 24 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
|
MKWI50
(10) |
2" X 1" | 50W | 9-36, 18-75 | 3.3, 5, 12, 15, 24 | 1500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
鉄道用
|
MTQZ50
(8) |
クォーターブリック | 50W | 43-101, 66-160 | 5, 12, 15, 24 | 3000VAC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 EN50155 EN45545-2 CB-Report CE-Marking | ||
|
産業用
|
MRWI60C
(8) |
シャーシ, DINレール | 60W | 9-36, 18-75 | 5.1, 12, 24, 48 | 2500VDC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 CB-Report CE-Marking | ||
|
産業用
鉄道用
|
MTQZ75
(8) |
クォーターブリック | 75W | 43-101, 66-160 | 5, 12, 15, 24 | 3000VAC | UL/cUL/IEC/EN 60950-1 UL/cUL/IEC/EN 62368-1 EN50155 EN45545-2 CB-Report CE-Marking |
